The Kaskinen Project was designed for construction using aerated concrete masonry technology.
1. Technical and Economic Indicators
-
Floors: 1.5
-
Building footprint: 154.9 m²
-
Usable area: 215.3 m²
-
Porch area: 5.3 m²
-
Terrace area: 57.1 m²
-
Balcony area: 6.2 m²
2. Volume and Layout
Ceiling heights:
-
First floor: 3.0 m
-
Second floor (attic):
-
Minimum: 0.75 m
-
Maximum: 2.7 m
-
3. Structural Solutions
-
Structural system: load-bearing walls
-
Foundation: monolithic reinforced concrete slab or strip foundation
-
Exterior walls: 400 mm aerated concrete blocks
-
Interior walls: 250 mm aerated concrete blocks
-
Partitions: 150 mm aerated concrete blocks
-
Roof: standing seam metal roof
-
Facade finish:
-
First floor: decorative plaster and clinker brick
-
Attic floor: timber imitation, plank siding, or “Cedral”
-
-
Porch covering: larch decking
-
Rainwater drainage: gutters and downpipes
4. Engineering Systems
-
Electricity: from external grid
-
Cold water: from external supply
-
Hot water: indirect heating boiler
-
Sewage: local treatment station
-
Heating: electric
This design combines modern aerated concrete construction with practical layout solutions for spacious and comfortable living, including terraces and balconies for outdoor enjoyment.
